Product Specification
Display 2.7 inch TFT-LCD
Bladder output range Bladder volume range : 0 – 999ml
Accuracy : 0-99ml±10ml, 100-999ml±10%
Scan time Less than 2 sec
Ultrasound probe Ultrasound frequency : 2MHz, 3.4MHz (Dual)
Scan angle : 120º
Penetration depth : 23cm (Normal patient)
Power Rechargeable Li-ion battery
Nominal voltage : 3.6V
Nominal capacity : 5200mAh
Charging : less than 6 hours
Discharging : Approximately 1000 scans
Charged by the docking station
External interface USB 2.0 basic
Patient ID input Virtual keyboard
1D/2D barcode (optional), class I
User interface LCD Icons and 2 buttons
Printer Built-in thermal printer in the docking station
(Wireless data transmission by IrDA)
